Just keeping this updated. I have begun maintenance phase of my other project, mythicalLibrarian. This means I have stopped adding features to it and am only taking support/bug requests.
I have begun learning Java programming language. I have written my first java program which is the "fizzbuzz" program. Mine came out quite a bit differently then the example which I did not peek at. I am still learning and it will be a lenghty process.
1. learn java to the point where I can communicate with the filesystem
2. establish communications with the ELM327 device
3. establish rolling communications with the elm 327 device
this will be the most important part. It requires being able to process whatever the ELM327 has sent between > and >, then taking that and processing it into a variable.
4. build a library for operations on all elm commands including things like how to decipher RPM information and MAF information, then putting them into the RPM and MAF variables. *LONG LONG LONG PROCESS*
5. Build a GUI. My brother who is a full time computer programmer who works with java in his job has agreed to help with this.
4 and 5 will happen simultaniously.
6. Build a version of linux which will be the Ultimate Tuner OS as was the original goal in this thread. Load Linux>Gnome>Program
7. port to Android so that it becomes easy to add a gauge to the side of your instrument panel
I have begun learning Java programming language. I have written my first java program which is the "fizzbuzz" program. Mine came out quite a bit differently then the example which I did not peek at. I am still learning and it will be a lenghty process.
1. learn java to the point where I can communicate with the filesystem
2. establish communications with the ELM327 device
3. establish rolling communications with the elm 327 device
this will be the most important part. It requires being able to process whatever the ELM327 has sent between > and >, then taking that and processing it into a variable.
4. build a library for operations on all elm commands including things like how to decipher RPM information and MAF information, then putting them into the RPM and MAF variables. *LONG LONG LONG PROCESS*
5. Build a GUI. My brother who is a full time computer programmer who works with java in his job has agreed to help with this.
4 and 5 will happen simultaniously.
6. Build a version of linux which will be the Ultimate Tuner OS as was the original goal in this thread. Load Linux>Gnome>Program
7. port to Android so that it becomes easy to add a gauge to the side of your instrument panel
Thread Starter
Moderator
Joined: Feb 2009
Posts: 11,732
Likes: 5
From: Leesville, Louisiana
Vehicle: 2001 Hyundai Tiburon
I learned Java programming language. It's quite simliar to BASH scripting and C#. Over 100 sensors have been outlined into OBD 2ner. Most are not yet functional. I have calculated load value working. Still no GUI or read capabilities yet. I'm working on the processing still.
I need help with a mode $08 scan http://www.rdtiburon.com/index.php?showtop...mp;#entry425084 I am busy inside the house. If anyone can attend their car, it would be good for the entire Hyundai community. You can also learn something.
I need help with a mode $08 scan http://www.rdtiburon.com/index.php?showtop...mp;#entry425084 I am busy inside the house. If anyone can attend their car, it would be good for the entire Hyundai community. You can also learn something.
Thread Starter
Moderator
Joined: Feb 2009
Posts: 11,732
Likes: 5
From: Leesville, Louisiana
Vehicle: 2001 Hyundai Tiburon
I'm pretty proud right now. This marks the moment OBD2ner went online.
Keep in mind that there is still no GUI. It's all text based. The little window on the left bottom corner of the right monitor is the output data.
Keep in mind that there is still no GUI. It's all text based. The little window on the left bottom corner of the right monitor is the output data.
Super Moderator
Joined: Sep 2001
Posts: 10,795
Likes: 5
From: Pflugerville, TX
Vehicle: 2000 Elantra
Dude, crop. Seriously.
and, I still don't see anything exciting. What is that, aside from a communications link established through a computer program . . . or was that the hard part? I don't know, I just use computers and curse/repair them when they break. Programming I leave to others more passionate or better-paid than I am. Let's have a gauge per sensor, with a fancy twiddly bit to adjust whatever, then you'll get more people excited. For now it looks like the gobbledygook that everyone enjoys not knowing about.
and, I still don't see anything exciting. What is that, aside from a communications link established through a computer program . . . or was that the hard part? I don't know, I just use computers and curse/repair them when they break. Programming I leave to others more passionate or better-paid than I am. Let's have a gauge per sensor, with a fancy twiddly bit to adjust whatever, then you'll get more people excited. For now it looks like the gobbledygook that everyone enjoys not knowing about.
Thread Starter
Moderator
Joined: Feb 2009
Posts: 11,732
Likes: 5
From: Leesville, Louisiana
Vehicle: 2001 Hyundai Tiburon
Establishing online communications is the hardest part. This means I can now query the car for data
All libraries are in place for mode $01, $02, $03, $04, $05, $07, $09, and $0A. Which means all non-manufacturer specific data is now interperated into actual physical data. This also means that the only thing missing is a GUI. I will be quality checking my data before continuing any further, but that data is from the elm unit. Now the project takes a different direction.... Artwork.
All libraries are in place for mode $01, $02, $03, $04, $05, $07, $09, and $0A. Which means all non-manufacturer specific data is now interperated into actual physical data. This also means that the only thing missing is a GUI. I will be quality checking my data before continuing any further, but that data is from the elm unit. Now the project takes a different direction.... Artwork.
Super Moderator
Joined: Sep 2001
Posts: 10,795
Likes: 5
From: Pflugerville, TX
Vehicle: 2000 Elantra
Okay, so now what you're saying is you "just" have to work on putting the numbers on to onscreen displays, and you can see what the car is saying about itself? That's pretty neat.
Thread Starter
Moderator
Joined: Feb 2009
Posts: 11,732
Likes: 5
From: Leesville, Louisiana
Vehicle: 2001 Hyundai Tiburon
^^ What? oh, wait, you think... here read this:
The program works and can extract data from the car. It just needs to look all fluffy and artsy fartsy in order to be usable by most humans. it works. it just needs a graphic interface.
very funny radu.
CODE
switching mode:atz
switching mode:ELM327 v1.3a
Data Requested....>at@1
switching mode:OBDII to RS232 Interpreter
Data Requested....>at@2
INVALID REQUEST RETURNED:?
Data Requested....>0901
switching mode:NO DATA
Data Requested....>090001
switching mode:NO DATA
Data Requested....>090100
switching mode:NO DATA
Data Requested....>61 6A F1 01 0C
switching mode:NO DATA
Data Requested....>
switching mode:NO DATA
Data Requested....>0101
switching mode:41 01 00 07 6D 00
Request: 01
Binary to Array:[false, false, false, false, false, false, false, false]
Binary to Array:[true, true, true, false, false, false, false, false]
Binary to Array:[true, false, true, true, false, true, true, false]
Binary to Array:[false, false, false, false, false, false, false, false]
CheckEngineLight:OFF
NumberOfDiagnosticCodes:0
Misfire status:Test Complete
Fuel System status:Test Complete
Components status:Test Complete
Reserved status:Test Not Available
Catalyst status:Test Complete
Heated Catalyst status:Test Not Available
Evaporative status:Test Complete
Secondary Air System status:Test Complete
Refrigerant status:Test Not Available
O2 Sensor status:Test Complete
O2 Sensor Heater status:Test Complete
EGR System status:Test Not Available
switching mode:41 01 00 04 00 00
Request: 01
Binary to Array:[false, false, false, false, false, false, false, false]
Binary to Array:[false, false, true, false, false, false, false, false]
Binary to Array:[false, false, false, false, false, false, false, false]
Binary to Array:[false, false, false, false, false, false, false, false]
CheckEngineLight:OFF
NumberOfDiagnosticCodes:0
Misfire status:Test Not Available
Fuel System status:Test Not Available
Components status:Test Complete
Reserved status:Test Not Available
Catalyst status:Test Not Available
Heated Catalyst status:Test Not Available
Evaporative status:Test Not Available
Secondary Air System status:Test Not Available
Refrigerant status:Test Not Available
O2 Sensor status:Test Not Available
O2 Sensor Heater status:Test Not Available
EGR System status:Test Not Available
Data Requested....>0102
switching mode:NO DATA
Data Requested....>0103
switching mode:41 03 02 02
Request: 03
Binary to Array:[false, true, false, false, false, false, false, false]
Binary to Array:[false, true, false, false, false, false, false, false]
Fuel System Status:CLOSED LOOP-Using O2 feedback for A/F Ratio
Secondary Fuel System Status: CLOSED LOOP-Using O2 feedback for A/F Ratio
Data Requested....>0104
switching mode:41 04 0C
Request: 04
EngineLoad:4.7058825%
Data Requested....>0105
switching mode:41 05 73
Request: 05
coolantTemp=75.0C
coolantTemp=107.0F
switching mode:41 05 54
Request: 05
coolantTemp=44.0C
coolantTemp=76.0F
Data Requested....>0106
switching mode:41 06 83
Request: 06
Short Term Fuel Trim Bank 1: 2.0
Data Requested....>0107
switching mode:41 07 7A
Request: 07
Long Term Fuel Trim Bank 1:-4.0
Data Requested....>0107
switching mode:41 07 7A
Request: 07
Long Term Fuel Trim Bank 1:-4.0
Data Requested....>0900
switching mode:49 00 01 3C 00 00 00
0001
switching mode:49 00 3C 00 00 00
003C
Data Requested....>090000
switching mode:NO DATA
Data Requested....>090100
switching mode:NO DATA
Data Requested....>09010101010
Data Requested....>0901000000000
Data Requested....>atz
switching mode:ELM327 v1.3a
Data Requested....>F006C410F122164800000000
INVALID REQUEST RETURNED:?
Data Requested....>
INVALID REQUEST RETURNED:?
Data Requested....>atz
switching mode:ELM327 v1.3a
Data Requested....>020000
switching mode:42 00 00 40 00 00 00
00
Binary To String: 00000000
Binary To String: 01000000
Binary To String: 00000000
Binary To String: 00000000
Input Binary String:00000000010000000000000000000000
Output Array:[false, false, false, false, false, false, false, false, false, true, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false]
PIDs 01-20:[false, false, false, false, false, false, false, false, false, true, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false]
switching mode:42 00 00 40 00 00 00
00
Binary To String: 00000000
Binary To String: 01000000
Binary To String: 00000000
Binary To String: 00000000
Input Binary String:00000000010000000000000000000000
Output Array:[false, false, false, false, false, false, false, false, false, true, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false]
PIDs 01-20:[false, false, false, false, false, false, false, false, false, true, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false]
Data Requested....>0901
switching mode:NO DATA
Data Requested....>0900
switching mode:49 00 3C 00 00 00
003C
switching mode:49 00 01 3C 00 00 00
0001
Data Requested....>0801
switching mode:NO DATA
Data Requested....>0901
switching mode:NO DATA
Data Requested....>0901pid02
INVALID REQUEST RETURNED:?
Data Requested....>090101
switching mode:NO DATA
Data Requested....>09010101
switching mode:NO DATA
Data Requested....>090102
switching mode:NO DATA
Data Requested....>0801
switching mode:NO DATA
Data Requested....>080101
switching mode:NO DATA
Data Requested....>080001
switching mode:NO DATA
Data Requested....>080100
switching mode:NO DATA
Data Requested....>0802
switching mode:NO DATA
Data Requested....>0803
switching mode:NO DATA
Data Requested....>0804
switching mode:NO DATA
Data Requested....>0805
switching mode:NO DATA
Data Requested....>0806
switching mode:NO DATA
Data Requested....>42686af10100
switching mode:NO DATA
Data Requested....>06 TID
INVALID REQUEST RETURNED:?
Data Requested....>06
switching mode:NO DATA
Data Requested....>0601
switching mode:46 01 05 00 82 00 94
switching mode:46 01 06 00 74 00 94
Data Requested....>93
switching mode:NO DATA
Data Requested....>C9B1B2B3B4B5B6B7B8
INVALID REQUEST RETURNED:?
Data Requested....>
INVALID REQUEST RETURNED:?
Data Requested....>42
switching mode:NO DATA
Data Requested....>at42
INVALID REQUEST RETURNED:?
Data Requested....>T CRA 7E9
INVALID REQUEST RETURNED:?
Data Requested....>
INVALID REQUEST RETURNED:?
Data Requested....>aT CRA 7E9
switching mode:OK
Data Requested....>0001
switching mode:NO DATA
Data Requested....>0101
switching mode:41 01 00 07 6D 00
Request: 01
Binary to Array:[false, false, false, false, false, false, false, false]
Binary to Array:[true, true, true, false, false, false, false, false]
Binary to Array:[true, false, true, true, false, true, true, false]
Binary to Array:[false, false, false, false, false, false, false, false]
CheckEngineLight:OFF
NumberOfDiagnosticCodes:0
Misfire status:Test Complete
Fuel System status:Test Complete
Components status:Test Complete
Reserved status:Test Not Available
Catalyst status:Test Complete
Heated Catalyst status:Test Not Available
Evaporative status:Test Complete
Secondary Air System status:Test Complete
Refrigerant status:Test Not Available
O2 Sensor status:Test Complete
O2 Sensor Heater status:Test Complete
EGR System status:Test Not Available
switching mode:41 01 00 04 00 00
Request: 01
Binary to Array:[false, false, false, false, false, false, false, false]
Binary to Array:[false, false, true, false, false, false, false, false]
Binary to Array:[false, false, false, false, false, false, false, false]
Binary to Array:[false, false, false, false, false, false, false, false]
CheckEngineLight:OFF
NumberOfDiagnosticCodes:0
Misfire status:Test Not Available
Fuel System status:Test Not Available
Components status:Test Complete
Reserved status:Test Not Available
Catalyst status:Test Not Available
Heated Catalyst status:Test Not Available
Evaporative status:Test Not Available
Secondary Air System status:Test Not Available
Refrigerant status:Test Not Available
O2 Sensor status:Test Not Available
O2 Sensor Heater status:Test Not Available
EGR System status:Test Not Available
Data Requested....>0902
switching mode:NO DATA
Data Requested....>ath1
switching mode:OK
Data Requested....>0100
switching mode:48 6B 10 41 00 BF 9F F9 91 EC
information on mode 8 received: 48 6B 10 41 00 BF 9F F9 91 EC
switching mode:48 6B 1A 41 00 88 18 80 00 2E
information on mode 8 received: 48 6B 1A 41 00 88 18 80 00 2E
Data Requested....>0101
switching mode:48 6B 10 41 01 00 07 6D 00 79
information on mode 8 received: 48 6B 10 41 01 00 07 6D 00 79
switching mode:48 6B 1A 41 01 00 04 00 00 13
information on mode 8 received: 48 6B 1A 41 01 00 04 00 00 13
Data Requested....>08486b0101
switching mode:NO DATA
Data Requested....>0904
switching mode:48 6B 1A 49 04 38 44 30 39 32 37 <DATA ERROR
information on mode 8 received: 48 6B 1A 49 04 38 44 30 39 32 37 <DATA ERROR
switching mode:48 6B 10 49 04 01 30 30 30 31 D2
information on mode 8 received: 48 6B 10 49 04 01 30 30 30 31 D2
switching mode:48 6B 10 49 04 02 00 00 00 00 12
information on mode 8 received: 48 6B 10 49 04 02 00 00 00 00 12
switching mode:48 6B 10 49 04 03 00 00 00 00 13
information on mode 8 received: 48 6B 10 49 04 03 00 00 00 00 13
switching mode:48 6B 10 49 04 04 00 00 00 00 14
information on mode 8 received: 48 6B 10 49 04 04 00 00 00 00 14
switching mode:48 6B 1A 49 04 31 35 36 41 53 20 <DATA ERROR
information on mode 8 received: 48 6B 1A 49 04 31 35 36 41 53 20 <DATA ERROR
switching mode:48 6B 1A 49 04 33 31 33 32 E3
information on mode 8 received: 48 6B 1A 49 04 33 31 33 32 E3
Data Requested....>ath0
switching mode:OK
Data Requested....>0904
switching mode:49 04 01 30 30 30 31
0401
switching mode:49 04 02 00 00 00 00
0402
switching mode:49 04 03 00 00 00 00
0403
switching mode:49 04 04 00 00 00 00
0404
switching mode:49 04 38 44 30 39 32 <DATA ERROR
0438
switching mode:49 04 31 35 36 41 53 <DATA ERROR
0431
switching mode:49 04 33 31 33 32
0433
Data Requested....>0903
switching mode:49 03 04
0304
switching mode:49 03 03
0303
Data Requested....>0902
switching mode:NO DATA
Data Requested....>0905
switching mode:49 05 01
0501
switching mode:49 05 01
0501
Data Requested....>0906
switching mode:49 06 1C 21
061C
Data Requested....>atma
Data Requested....>TMA
INVALID REQUEST RETURNED:?
Data Requested....>ATMA
Data Requested....>tz
INVALID REQUEST RETURNED:?
Data Requested....>atz
switching mode:ELM327 v1.3a
Data Requested....>atma
switching mode:SEARCHING...
Data Requested....>T SH 7E0
INVALID REQUEST RETURNED:?
Data Requested....>
INVALID REQUEST RETURNED:?
Data Requested....>0105
switching mode:41 05 85
Request: 05
coolantTemp=93.0C
coolantTemp=125.0F
switching mode:41 05 78
Request: 05
coolantTemp=80.0C
coolantTemp=112.0F
Data Requested....>AT SH 7E0
switching mode:OK
Data Requested....>
switching mode:OK
Data Requested....>AT SH 7E0
switching mode:OK
Data Requested....>
switching mode:OK
Data Requested....>0105
switching mode:NO DATA
Data Requested....>atz
switching mode:ELM327 v1.3a
Data Requested....>0101
switching mode:41 01 00 07 6D 00
Request: 01
Binary to Array:[false, false, false, false, false, false, false, false]
Binary to Array:[true, true, true, false, false, false, false, false]
Binary to Array:[true, false, true, true, false, true, true, false]
Binary to Array:[false, false, false, false, false, false, false, false]
CheckEngineLight:OFF
NumberOfDiagnosticCodes:0
Misfire status:Test Complete
Fuel System status:Test Complete
Components status:Test Complete
Reserved status:Test Not Available
Catalyst status:Test Complete
Heated Catalyst status:Test Not Available
Evaporative status:Test Complete
Secondary Air System status:Test Complete
Refrigerant status:Test Not Available
O2 Sensor status:Test Complete
O2 Sensor Heater status:Test Complete
EGR System status:Test Not Available
switching mode:41 01 00 04 00 00
Request: 01
Binary to Array:[false, false, false, false, false, false, false, false]
Binary to Array:[false, false, true, false, false, false, false, false]
Binary to Array:[false, false, false, false, false, false, false, false]
Binary to Array:[false, false, false, false, false, false, false, false]
CheckEngineLight:OFF
NumberOfDiagnosticCodes:0
Misfire status:Test Not Available
Fuel System status:Test Not Available
Components status:Test Complete
Reserved status:Test Not Available
Catalyst status:Test Not Available
Heated Catalyst status:Test Not Available
Evaporative status:Test Not Available
Secondary Air System status:Test Not Available
Refrigerant status:Test Not Available
O2 Sensor status:Test Not Available
O2 Sensor Heater status:Test Not Available
EGR System status:Test Not Available
Data Requested....>atma
Data Requested....>T MP 00FECB
INVALID REQUEST RETURNED:?
Data Requested....>AT MP FECB
INVALID REQUEST RETURNED:?
Data Requested....>atdp
switching mode:AUTO, ISO 9141-2
Data Requested....>atdm1
INVALID REQUEST RETURNED:?
Data Requested....>at caf1
switching mode:OK
Data Requested....>at dm1
INVALID REQUEST RETURNED:?
Data Requested....>at caf1
switching mode:OK
Data Requested....>atdm1
INVALID REQUEST RETURNED:?
Data Requested....>atcaf1
switching mode:OK
Data Requested....>atz
switching mode:ELM327 v1.3a
Data Requested....>AT PP FF OFF
switching mode:OK
Data Requested....>
switching mode:OK
Data Requested....>0001
Data Requested....>tz
INVALID REQUEST RETURNED:?
Data Requested....>atz
switching mode:ELM327 v1.3a
Data Requested....>atz
switching mode:ELM327 v1.3a
Data Requested....>atz
switching mode:ELM327 v1.3a
Data Requested....>atz
switching mode:ELM327 v1.3a
Data Requested....>ath1
switching mode:OK
Data Requested....>0001
switching mode:NO DATA
Data Requested....>atppffoff
switching mode:OK
Data Requested....>0001
switching mode:NO DATA
Data Requested....>0101
switching mode:48 6B 1A 41 01 00 04 00 00 13
information on mode 8 received: 48 6B 1A 41 01 00 04 00 00 13
switching mode:48 6B 10 41 01 00 07 6D 00 79
information on mode 8 received: 48 6B 10 41 01 00 07 6D 00 79
Data Requested....>ath1
switching mode:OK
Data Requested....>0101
switching mode:48 6B 10 41 01 00 07 6D 00 79
information on mode 8 received: 48 6B 10 41 01 00 07 6D 00 79
switching mode:48 6B 1A 41 01 00 04 00 00 13
information on mode 8 received: 48 6B 1A 41 01 00 04 00 00 13
Data Requested....>atppffoff
switching mode:OK
Data Requested....>0101
switching mode:48 6B 1A 41 01 00 04 00 00 13
information on mode 8 received: 48 6B 1A 41 01 00 04 00 00 13
switching mode:48 6B 10 41 01 00 07 6D 00 79
information on mode 8 received: 48 6B 10 41 01 00 07 6D 00 79
Data Requested....>atz
switching mode:ELM327 v1.3a
Data Requested....>0101
switching mode:SEARCHING...
switching mode:UNABLE TO CONNECT
Data Requested....>0101
switching mode:41 01 00 07 6D 00
Request: 01
Binary to Array:[false, false, false, false, false, false, false, false]
Binary to Array:[true, true, true, false, false, false, false, false]
Binary to Array:[true, false, true, true, false, true, true, false]
Binary to Array:[false, false, false, false, false, false, false, false]
CheckEngineLight:OFF
NumberOfDiagnosticCodes:0
Misfire status:Test Complete
Fuel System status:Test Complete
Components status:Test Complete
Reserved status:Test Not Available
Catalyst status:Test Complete
Heated Catalyst status:Test Not Available
Evaporative status:Test Complete
Secondary Air System status:Test Complete
Refrigerant status:Test Not Available
O2 Sensor status:Test Complete
O2 Sensor Heater status:Test Complete
EGR System status:Test Not Available
switching mode:41 01 00 04 00 00
Request: 01
Binary to Array:[false, false, false, false, false, false, false, false]
Binary to Array:[false, false, true, false, false, false, false, false]
Binary to Array:[false, false, false, false, false, false, false, false]
Binary to Array:[false, false, false, false, false, false, false, false]
CheckEngineLight:OFF
NumberOfDiagnosticCodes:0
Misfire status:Test Not Available
Fuel System status:Test Not Available
Components status:Test Complete
Reserved status:Test Not Available
Catalyst status:Test Not Available
Heated Catalyst status:Test Not Available
Evaporative status:Test Not Available
Secondary Air System status:Test Not Available
Refrigerant status:Test Not Available
O2 Sensor status:Test Not Available
O2 Sensor Heater status:Test Not Available
EGR System status:Test Not Available
Data Requested....>
switching mode:ELM327 v1.3a
Data Requested....>at@1
switching mode:OBDII to RS232 Interpreter
Data Requested....>at@2
INVALID REQUEST RETURNED:?
Data Requested....>0901
switching mode:NO DATA
Data Requested....>090001
switching mode:NO DATA
Data Requested....>090100
switching mode:NO DATA
Data Requested....>61 6A F1 01 0C
switching mode:NO DATA
Data Requested....>
switching mode:NO DATA
Data Requested....>0101
switching mode:41 01 00 07 6D 00
Request: 01
Binary to Array:[false, false, false, false, false, false, false, false]
Binary to Array:[true, true, true, false, false, false, false, false]
Binary to Array:[true, false, true, true, false, true, true, false]
Binary to Array:[false, false, false, false, false, false, false, false]
CheckEngineLight:OFF
NumberOfDiagnosticCodes:0
Misfire status:Test Complete
Fuel System status:Test Complete
Components status:Test Complete
Reserved status:Test Not Available
Catalyst status:Test Complete
Heated Catalyst status:Test Not Available
Evaporative status:Test Complete
Secondary Air System status:Test Complete
Refrigerant status:Test Not Available
O2 Sensor status:Test Complete
O2 Sensor Heater status:Test Complete
EGR System status:Test Not Available
switching mode:41 01 00 04 00 00
Request: 01
Binary to Array:[false, false, false, false, false, false, false, false]
Binary to Array:[false, false, true, false, false, false, false, false]
Binary to Array:[false, false, false, false, false, false, false, false]
Binary to Array:[false, false, false, false, false, false, false, false]
CheckEngineLight:OFF
NumberOfDiagnosticCodes:0
Misfire status:Test Not Available
Fuel System status:Test Not Available
Components status:Test Complete
Reserved status:Test Not Available
Catalyst status:Test Not Available
Heated Catalyst status:Test Not Available
Evaporative status:Test Not Available
Secondary Air System status:Test Not Available
Refrigerant status:Test Not Available
O2 Sensor status:Test Not Available
O2 Sensor Heater status:Test Not Available
EGR System status:Test Not Available
Data Requested....>0102
switching mode:NO DATA
Data Requested....>0103
switching mode:41 03 02 02
Request: 03
Binary to Array:[false, true, false, false, false, false, false, false]
Binary to Array:[false, true, false, false, false, false, false, false]
Fuel System Status:CLOSED LOOP-Using O2 feedback for A/F Ratio
Secondary Fuel System Status: CLOSED LOOP-Using O2 feedback for A/F Ratio
Data Requested....>0104
switching mode:41 04 0C
Request: 04
EngineLoad:4.7058825%
Data Requested....>0105
switching mode:41 05 73
Request: 05
coolantTemp=75.0C
coolantTemp=107.0F
switching mode:41 05 54
Request: 05
coolantTemp=44.0C
coolantTemp=76.0F
Data Requested....>0106
switching mode:41 06 83
Request: 06
Short Term Fuel Trim Bank 1: 2.0
Data Requested....>0107
switching mode:41 07 7A
Request: 07
Long Term Fuel Trim Bank 1:-4.0
Data Requested....>0107
switching mode:41 07 7A
Request: 07
Long Term Fuel Trim Bank 1:-4.0
Data Requested....>0900
switching mode:49 00 01 3C 00 00 00
0001
switching mode:49 00 3C 00 00 00
003C
Data Requested....>090000
switching mode:NO DATA
Data Requested....>090100
switching mode:NO DATA
Data Requested....>09010101010
Data Requested....>0901000000000
Data Requested....>atz
switching mode:ELM327 v1.3a
Data Requested....>F006C410F122164800000000
INVALID REQUEST RETURNED:?
Data Requested....>
INVALID REQUEST RETURNED:?
Data Requested....>atz
switching mode:ELM327 v1.3a
Data Requested....>020000
switching mode:42 00 00 40 00 00 00
00
Binary To String: 00000000
Binary To String: 01000000
Binary To String: 00000000
Binary To String: 00000000
Input Binary String:00000000010000000000000000000000
Output Array:[false, false, false, false, false, false, false, false, false, true, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false]
PIDs 01-20:[false, false, false, false, false, false, false, false, false, true, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false]
switching mode:42 00 00 40 00 00 00
00
Binary To String: 00000000
Binary To String: 01000000
Binary To String: 00000000
Binary To String: 00000000
Input Binary String:00000000010000000000000000000000
Output Array:[false, false, false, false, false, false, false, false, false, true, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false]
PIDs 01-20:[false, false, false, false, false, false, false, false, false, true, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false]
Data Requested....>0901
switching mode:NO DATA
Data Requested....>0900
switching mode:49 00 3C 00 00 00
003C
switching mode:49 00 01 3C 00 00 00
0001
Data Requested....>0801
switching mode:NO DATA
Data Requested....>0901
switching mode:NO DATA
Data Requested....>0901pid02
INVALID REQUEST RETURNED:?
Data Requested....>090101
switching mode:NO DATA
Data Requested....>09010101
switching mode:NO DATA
Data Requested....>090102
switching mode:NO DATA
Data Requested....>0801
switching mode:NO DATA
Data Requested....>080101
switching mode:NO DATA
Data Requested....>080001
switching mode:NO DATA
Data Requested....>080100
switching mode:NO DATA
Data Requested....>0802
switching mode:NO DATA
Data Requested....>0803
switching mode:NO DATA
Data Requested....>0804
switching mode:NO DATA
Data Requested....>0805
switching mode:NO DATA
Data Requested....>0806
switching mode:NO DATA
Data Requested....>42686af10100
switching mode:NO DATA
Data Requested....>06 TID
INVALID REQUEST RETURNED:?
Data Requested....>06
switching mode:NO DATA
Data Requested....>0601
switching mode:46 01 05 00 82 00 94
switching mode:46 01 06 00 74 00 94
Data Requested....>93
switching mode:NO DATA
Data Requested....>C9B1B2B3B4B5B6B7B8
INVALID REQUEST RETURNED:?
Data Requested....>
INVALID REQUEST RETURNED:?
Data Requested....>42
switching mode:NO DATA
Data Requested....>at42
INVALID REQUEST RETURNED:?
Data Requested....>T CRA 7E9
INVALID REQUEST RETURNED:?
Data Requested....>
INVALID REQUEST RETURNED:?
Data Requested....>aT CRA 7E9
switching mode:OK
Data Requested....>0001
switching mode:NO DATA
Data Requested....>0101
switching mode:41 01 00 07 6D 00
Request: 01
Binary to Array:[false, false, false, false, false, false, false, false]
Binary to Array:[true, true, true, false, false, false, false, false]
Binary to Array:[true, false, true, true, false, true, true, false]
Binary to Array:[false, false, false, false, false, false, false, false]
CheckEngineLight:OFF
NumberOfDiagnosticCodes:0
Misfire status:Test Complete
Fuel System status:Test Complete
Components status:Test Complete
Reserved status:Test Not Available
Catalyst status:Test Complete
Heated Catalyst status:Test Not Available
Evaporative status:Test Complete
Secondary Air System status:Test Complete
Refrigerant status:Test Not Available
O2 Sensor status:Test Complete
O2 Sensor Heater status:Test Complete
EGR System status:Test Not Available
switching mode:41 01 00 04 00 00
Request: 01
Binary to Array:[false, false, false, false, false, false, false, false]
Binary to Array:[false, false, true, false, false, false, false, false]
Binary to Array:[false, false, false, false, false, false, false, false]
Binary to Array:[false, false, false, false, false, false, false, false]
CheckEngineLight:OFF
NumberOfDiagnosticCodes:0
Misfire status:Test Not Available
Fuel System status:Test Not Available
Components status:Test Complete
Reserved status:Test Not Available
Catalyst status:Test Not Available
Heated Catalyst status:Test Not Available
Evaporative status:Test Not Available
Secondary Air System status:Test Not Available
Refrigerant status:Test Not Available
O2 Sensor status:Test Not Available
O2 Sensor Heater status:Test Not Available
EGR System status:Test Not Available
Data Requested....>0902
switching mode:NO DATA
Data Requested....>ath1
switching mode:OK
Data Requested....>0100
switching mode:48 6B 10 41 00 BF 9F F9 91 EC
information on mode 8 received: 48 6B 10 41 00 BF 9F F9 91 EC
switching mode:48 6B 1A 41 00 88 18 80 00 2E
information on mode 8 received: 48 6B 1A 41 00 88 18 80 00 2E
Data Requested....>0101
switching mode:48 6B 10 41 01 00 07 6D 00 79
information on mode 8 received: 48 6B 10 41 01 00 07 6D 00 79
switching mode:48 6B 1A 41 01 00 04 00 00 13
information on mode 8 received: 48 6B 1A 41 01 00 04 00 00 13
Data Requested....>08486b0101
switching mode:NO DATA
Data Requested....>0904
switching mode:48 6B 1A 49 04 38 44 30 39 32 37 <DATA ERROR
information on mode 8 received: 48 6B 1A 49 04 38 44 30 39 32 37 <DATA ERROR
switching mode:48 6B 10 49 04 01 30 30 30 31 D2
information on mode 8 received: 48 6B 10 49 04 01 30 30 30 31 D2
switching mode:48 6B 10 49 04 02 00 00 00 00 12
information on mode 8 received: 48 6B 10 49 04 02 00 00 00 00 12
switching mode:48 6B 10 49 04 03 00 00 00 00 13
information on mode 8 received: 48 6B 10 49 04 03 00 00 00 00 13
switching mode:48 6B 10 49 04 04 00 00 00 00 14
information on mode 8 received: 48 6B 10 49 04 04 00 00 00 00 14
switching mode:48 6B 1A 49 04 31 35 36 41 53 20 <DATA ERROR
information on mode 8 received: 48 6B 1A 49 04 31 35 36 41 53 20 <DATA ERROR
switching mode:48 6B 1A 49 04 33 31 33 32 E3
information on mode 8 received: 48 6B 1A 49 04 33 31 33 32 E3
Data Requested....>ath0
switching mode:OK
Data Requested....>0904
switching mode:49 04 01 30 30 30 31
0401
switching mode:49 04 02 00 00 00 00
0402
switching mode:49 04 03 00 00 00 00
0403
switching mode:49 04 04 00 00 00 00
0404
switching mode:49 04 38 44 30 39 32 <DATA ERROR
0438
switching mode:49 04 31 35 36 41 53 <DATA ERROR
0431
switching mode:49 04 33 31 33 32
0433
Data Requested....>0903
switching mode:49 03 04
0304
switching mode:49 03 03
0303
Data Requested....>0902
switching mode:NO DATA
Data Requested....>0905
switching mode:49 05 01
0501
switching mode:49 05 01
0501
Data Requested....>0906
switching mode:49 06 1C 21
061C
Data Requested....>atma
Data Requested....>TMA
INVALID REQUEST RETURNED:?
Data Requested....>ATMA
Data Requested....>tz
INVALID REQUEST RETURNED:?
Data Requested....>atz
switching mode:ELM327 v1.3a
Data Requested....>atma
switching mode:SEARCHING...
Data Requested....>T SH 7E0
INVALID REQUEST RETURNED:?
Data Requested....>
INVALID REQUEST RETURNED:?
Data Requested....>0105
switching mode:41 05 85
Request: 05
coolantTemp=93.0C
coolantTemp=125.0F
switching mode:41 05 78
Request: 05
coolantTemp=80.0C
coolantTemp=112.0F
Data Requested....>AT SH 7E0
switching mode:OK
Data Requested....>
switching mode:OK
Data Requested....>AT SH 7E0
switching mode:OK
Data Requested....>
switching mode:OK
Data Requested....>0105
switching mode:NO DATA
Data Requested....>atz
switching mode:ELM327 v1.3a
Data Requested....>0101
switching mode:41 01 00 07 6D 00
Request: 01
Binary to Array:[false, false, false, false, false, false, false, false]
Binary to Array:[true, true, true, false, false, false, false, false]
Binary to Array:[true, false, true, true, false, true, true, false]
Binary to Array:[false, false, false, false, false, false, false, false]
CheckEngineLight:OFF
NumberOfDiagnosticCodes:0
Misfire status:Test Complete
Fuel System status:Test Complete
Components status:Test Complete
Reserved status:Test Not Available
Catalyst status:Test Complete
Heated Catalyst status:Test Not Available
Evaporative status:Test Complete
Secondary Air System status:Test Complete
Refrigerant status:Test Not Available
O2 Sensor status:Test Complete
O2 Sensor Heater status:Test Complete
EGR System status:Test Not Available
switching mode:41 01 00 04 00 00
Request: 01
Binary to Array:[false, false, false, false, false, false, false, false]
Binary to Array:[false, false, true, false, false, false, false, false]
Binary to Array:[false, false, false, false, false, false, false, false]
Binary to Array:[false, false, false, false, false, false, false, false]
CheckEngineLight:OFF
NumberOfDiagnosticCodes:0
Misfire status:Test Not Available
Fuel System status:Test Not Available
Components status:Test Complete
Reserved status:Test Not Available
Catalyst status:Test Not Available
Heated Catalyst status:Test Not Available
Evaporative status:Test Not Available
Secondary Air System status:Test Not Available
Refrigerant status:Test Not Available
O2 Sensor status:Test Not Available
O2 Sensor Heater status:Test Not Available
EGR System status:Test Not Available
Data Requested....>atma
Data Requested....>T MP 00FECB
INVALID REQUEST RETURNED:?
Data Requested....>AT MP FECB
INVALID REQUEST RETURNED:?
Data Requested....>atdp
switching mode:AUTO, ISO 9141-2
Data Requested....>atdm1
INVALID REQUEST RETURNED:?
Data Requested....>at caf1
switching mode:OK
Data Requested....>at dm1
INVALID REQUEST RETURNED:?
Data Requested....>at caf1
switching mode:OK
Data Requested....>atdm1
INVALID REQUEST RETURNED:?
Data Requested....>atcaf1
switching mode:OK
Data Requested....>atz
switching mode:ELM327 v1.3a
Data Requested....>AT PP FF OFF
switching mode:OK
Data Requested....>
switching mode:OK
Data Requested....>0001
Data Requested....>tz
INVALID REQUEST RETURNED:?
Data Requested....>atz
switching mode:ELM327 v1.3a
Data Requested....>atz
switching mode:ELM327 v1.3a
Data Requested....>atz
switching mode:ELM327 v1.3a
Data Requested....>atz
switching mode:ELM327 v1.3a
Data Requested....>ath1
switching mode:OK
Data Requested....>0001
switching mode:NO DATA
Data Requested....>atppffoff
switching mode:OK
Data Requested....>0001
switching mode:NO DATA
Data Requested....>0101
switching mode:48 6B 1A 41 01 00 04 00 00 13
information on mode 8 received: 48 6B 1A 41 01 00 04 00 00 13
switching mode:48 6B 10 41 01 00 07 6D 00 79
information on mode 8 received: 48 6B 10 41 01 00 07 6D 00 79
Data Requested....>ath1
switching mode:OK
Data Requested....>0101
switching mode:48 6B 10 41 01 00 07 6D 00 79
information on mode 8 received: 48 6B 10 41 01 00 07 6D 00 79
switching mode:48 6B 1A 41 01 00 04 00 00 13
information on mode 8 received: 48 6B 1A 41 01 00 04 00 00 13
Data Requested....>atppffoff
switching mode:OK
Data Requested....>0101
switching mode:48 6B 1A 41 01 00 04 00 00 13
information on mode 8 received: 48 6B 1A 41 01 00 04 00 00 13
switching mode:48 6B 10 41 01 00 07 6D 00 79
information on mode 8 received: 48 6B 10 41 01 00 07 6D 00 79
Data Requested....>atz
switching mode:ELM327 v1.3a
Data Requested....>0101
switching mode:SEARCHING...
switching mode:UNABLE TO CONNECT
Data Requested....>0101
switching mode:41 01 00 07 6D 00
Request: 01
Binary to Array:[false, false, false, false, false, false, false, false]
Binary to Array:[true, true, true, false, false, false, false, false]
Binary to Array:[true, false, true, true, false, true, true, false]
Binary to Array:[false, false, false, false, false, false, false, false]
CheckEngineLight:OFF
NumberOfDiagnosticCodes:0
Misfire status:Test Complete
Fuel System status:Test Complete
Components status:Test Complete
Reserved status:Test Not Available
Catalyst status:Test Complete
Heated Catalyst status:Test Not Available
Evaporative status:Test Complete
Secondary Air System status:Test Complete
Refrigerant status:Test Not Available
O2 Sensor status:Test Complete
O2 Sensor Heater status:Test Complete
EGR System status:Test Not Available
switching mode:41 01 00 04 00 00
Request: 01
Binary to Array:[false, false, false, false, false, false, false, false]
Binary to Array:[false, false, true, false, false, false, false, false]
Binary to Array:[false, false, false, false, false, false, false, false]
Binary to Array:[false, false, false, false, false, false, false, false]
CheckEngineLight:OFF
NumberOfDiagnosticCodes:0
Misfire status:Test Not Available
Fuel System status:Test Not Available
Components status:Test Complete
Reserved status:Test Not Available
Catalyst status:Test Not Available
Heated Catalyst status:Test Not Available
Evaporative status:Test Not Available
Secondary Air System status:Test Not Available
Refrigerant status:Test Not Available
O2 Sensor status:Test Not Available
O2 Sensor Heater status:Test Not Available
EGR System status:Test Not Available
Data Requested....>
The program works and can extract data from the car. It just needs to look all fluffy and artsy fartsy in order to be usable by most humans. it works. it just needs a graphic interface.
very funny radu.
Super Moderator
Joined: Sep 2001
Posts: 10,795
Likes: 5
From: Pflugerville, TX
Vehicle: 2000 Elantra
OK that's a) too long and b) greek to me. I just want a frikken color head-up display on my windshield with a gauge for every sensor on the car, plus a few programmable gauges, and a pony. Is that really too much to ask?
Here's one I don't need a gauge for, though:
Here's one I don't need a gauge for, though:
QUOTE
switching mode:41 01 00 04 00 00
Request: 01
Binary to Array:[false, false, false, false, false, false, false, false]
Binary to Array:[false, false, true, false, false, false, false, false]
Binary to Array:[false, false, false, false, false, false, false, false]
Binary to Array:[false, false, false, false, false, false, false, false]
Request: 01
Binary to Array:[false, false, false, false, false, false, false, false]
Binary to Array:[false, false, true, false, false, false, false, false]
Binary to Array:[false, false, false, false, false, false, false, false]
Binary to Array:[false, false, false, false, false, false, false, false]
